The IrLugX TM series are true SWaP yet affordable thermal imaging camera cores. With shutterless technology, each IrLugX TM generates outstanding thermal profile. Among  them, IrLugX1M3 is the most compact and lightest high resolution LWIR core ever, ideal for long-range observation and surveillance.

Device-ALab

Plug and play
Compact & lightweight
Low power
Up to 60 fps
Multiple standard video interfaces

Technical Information

IrLugX™ (12µm pixel) 320 640 1M3
Resolution (pixels) 320 x 240 640x480 1280x1024
Frame rate (maximum) 60 Hz 60 Hz 60 Hz
Typical NETD (F/1 ; 300K ; 30 Hz) 50 mK 40 mK 40 mK



Product Interfaces / Video standards
Modules (host-based processing) RAW16 over USB2.0 or USB3.0
Engine Cores (embedded processing) BT656  /  YCbCr  /  CMOS parallel 16bit  /  PAL-NTSC /  Camera Link  /
SD-SDI  /  3G/HD-SDI  /  MIPI
Platforms (for handheld devices) Digital: BT656 / YCbCr  and/or Analog : PAL / NTSC



Others
Image processing Bad Pixel Correction, NUC, Shutterless
Image optimization Global/local AGC, Progressive digital zoom up to x4, Overlays
Optics (optional) 1.5 mm to 100+ mm Focal Distance /  4° to 180° HFOV
Operating temperature range Up to -40°C to +70°C (Extended or Military grade)
Qualifications MIL-STD-810G and MIL-STD-883 (TWS)

Description

The IrLugX TM uncooled LWIR camera series offer an affordable solution in thermal imaging. With resolutions up to 1280 x 1024 micro-bolometer in 12 μm pixels and SWaP design, IrLugX TM offer an outstanding thermal profile enabling low-power consumption, agility of configurations and plug & play solution for medium to high volume OEMs and integrators.



Features
  • Compact and feather-weighted
  • Easy to integrate
  • Low-power consumption



Options available

IrLugX1M3 ™

IrLugX1M3 ™

Specifications

IrLugX1M3

The IrLugX1M3TM is powered by 1280x1024 pixels bolometric sensor providing excellent thermal profile with typical NETD of 40 mK. The IrLugX1M3 TM is the solution for demanding OEMs and integrators in long-range observation and surveillance.

Request for a quote

IrLugX640 ™

IrLugX640 ™

Specifications

IrLugX640

The IrLugX640 TM is powered by 640x480 pixels bolometric sensor providing excellent thermal profile with typical NETD of 40mK. The IrLugX640 TM is the among the most compact and lightest VGA thermal imaging camera in the world.

Request for a quote

IrLugX320 ™

IrLugX320 ™

Specifications

IrLugX320

The IrLugX320 TM is powered by 320x240 pixels bolometric sensor with typical NETD of 50 mK. This uncooled infrared camera core is the solution for integrators of handheld infrared devices.



Request for a quote

Documentation

Brochure/Leaflet

SmartIR640 focusing distance 60cm (object size 30cm)

Did you know ?

Many users such Special Forces, police, security and maritime units, medical institutions have been using IrLugX TM.
